Enabling multiple Document Set views

byDan Sanders inSharePoint posted20 September, 2017

224

This article describes the view constraint you get out of the box with a Document Set in SharePoint. How we can enable multiple views to empower our end users. And how we can set the focus on a Web Part within a page.
Switching between views in Document Sets is particularly useful when the default view is grouped by a column which results in the Quick Edit/Datasheet View feature to be disabled.

The Document Set View Constraint

A Document Set is a group of related documents that you can manage as a single entity. You can create a Document Set in a single step, and then define its characteristics and metadata which can then populate through to the documents in the collection. Learn more about what you can do with a Document Sets

When you add the Document Set content type to a library it will inherit the default view of that library. The view is set in the Document Set Settings Welcome Page View section.
We can change this welcome page view by navigating to Document Library Settings > Select the Document Set Content Type > Click Document Set Settings link > Scroll to the Welcome Page View section

This allows you to have one default view at a library level and a different view inside the Document Set. The Welcome Page View is used for all instances of the Document Set. With multiple Document Set content types in a library you can specify a different view for each one.

What it looks like

When browsing the below document library the ‘a) Recently Modified’ view is set as default

Document Set in Library

Navigating into the Document Set switches the view so that we can present the properties in a relevant way.

Inside a Document Set

You will notice from the screenshot that I no longer have the ability to change views.
Furthermore, because I am grouping by Document Type, I can no longer Quick Edit the contents of this Document Set.
Not being able to quick edit makes it challenging to bulk update metadata when dragging multiple files into the library.

Enabling multiple views in a Document Set

To enable multiple views in a Document Set is actually quite simple. I discovered this primarily because I was tasked to update multiple libraries with an alternative solution that involved using Workflow. To save time and frustration I came up with the below.

Create a Document Set and browse its contents
Edit the page
Remove the Web Part in Zone 3 titled Document Set Contents

Document Set Contents Web Part

Add the document library App Web Part into Zone 3.
(This is the Document Library that your Document Set is sitting in)
Modify the Web Part and set your desired default view

Document Set Web PPart Properties

Save all and stop editing the page

Please note that you have edited the Welcome Page for all Document Sets in the library. You do not need to do this for every Document Set.

Now we can now select different views on the Document Set.

Multiple Views

When selecting a view, the view page is loaded filtered by the Document Set.

There is a slight drawback with this method. When browsing the contents of the Document Set, the Library ribbon does not show by default.

The reason for this is that there are multiple Web Parts on the page. On page load SharePoint does not know which Web Part to focus on and so doesn’t. If we select the Web Part the ribbon will load as above. The original Document Set Contents Web Part is special in that it steals the focus on load.

We can set the focus automatically by using some JavaScript as detailed below.

How to focus the new Web Part

Focusing a Web Part on page load is useful to show the relating ribbon tools. The focus is lost when there are multiple Web Parts per page.

This step involves adding a Script Editor Web Part to the Document Set Welcome Page with the following

<script type="text/javascript">
setTimeout(function () {
 // Grab the 4th Web Part
 elem = document.getElementById("MSOZoneCell_WebPartWPQ4");
 if (elem != null) {
  dummyevent = new Array();
  dummyevent["target"] = elem;
  dummyevent["srcElement"] = elem;
  WpClick(dummyevent);
 }
 // Update the name of the first view to Current View
 document.getElementById('WPQ4_ListTitleViewSelectorMenu_Container_surfaceopt0').innerText="Current View";
// Adjust the time to suit
}, 400);
</script>

Alternatively you can upload this as a txt file to Site Assets library of the Site Collection.
Then you can add a Content Editor Web Part with the content link to the txt file.

Document Set Focus Text File

This will save you having to paste the same code for each library. Be sure to set the Chrome Type to none.

An alternative way

The alternative way provides a way to filter a library view by Document Set contents. It does not allow the ability to change the view from within a Document Set. So for the user experience it is not so intuitive.

The Document Set Name property cannot be set as a Shared Column. However if we create a second name column on the Document Set we could use workflow to populate it.
This second name column can then be used as a Shared Column on the Document Set.

Setting shared columns populates the property through to the documents in the collection.

Then you could set up library views with the new name property. This will enable end users to filter documents by this value. These views require documents to be shown outside of folders and may breach the list view threshold on the library. The end user will need to navigate out of the Document Set to select the appropriate library view.

Using a simple SharePoint 2010 workflow to achieve this may not be the best idea when considering future upgrades.
